A 3-D model was printed 600 mm long.
This will help us evaluate the aerodynamic bodywork
This will help us evaluate the aerodynamic bodywork
Re: Fifty shades of Jade
Posted: Sat Dec 05, 20 7:34 pm
I'll just observe from a safe distance thank you...
Re: Fifty shades of Jade
Posted: Sun Dec 06, 20 4:21 pm
Fly by wire throttle FBW also know as Drive by wire Throttle DBW
The throttle will have no mechanical linkage to the throttle blade.
The throttle blade will be solely controlled by the onboard computer system.
Having an accurate and very reliable throttle position input from the rider is critical.
I though about thumb throttles and buttons but really wanted to utilise OEM equipment and the reliability that comes with it.
While DBW throttle pedals are very common in cars DBW motorcycle twist grips are rare / bulky / or a cable thing down to car style hall sensor mounted else where on the bike
I found a unit from a modern production Ducati that looks good.
The throttle will have no mechanical linkage to the throttle blade.
The throttle blade will be solely controlled by the onboard computer system.
Having an accurate and very reliable throttle position input from the rider is critical.
I though about thumb throttles and buttons but really wanted to utilise OEM equipment and the reliability that comes with it.
While DBW throttle pedals are very common in cars DBW motorcycle twist grips are rare / bulky / or a cable thing down to car style hall sensor mounted else where on the bike
I found a unit from a modern production Ducati that looks good.
Re: Fifty shades of Jade
Posted: Sun Dec 06, 20 4:30 pm
I think I'd rather have the rest of the Ducati than ride your sledge!!!!
Great work!
Great work!
Re: Fifty shades of Jade
Posted: Sun Dec 06, 20 4:31 pm
The unit was based around a low cost plastic handle with keyed clocked slots for position.
Using a cmm (coordinate measuring machine) we were able to quickly plot and reverse engineer this part into a CAD (Computer aided design) drawing.
Using a cmm (coordinate measuring machine) we were able to quickly plot and reverse engineer this part into a CAD (Computer aided design) drawing.
Re: Fifty shades of Jade
Posted: Sun Dec 06, 20 4:43 pm
Once we had the Ducati unit modelled in CAD we could create an aluminium version with would be a lot more robust and better suited for this application.
Re: Fifty shades of Jade
Posted: Sun Dec 06, 20 6:28 pm
Beautiful!!
Re: Fifty shades of Jade
Posted: Mon Dec 07, 20 12:33 pm
Man, you just keep taking it up a notch don't you!!!!
